A SURVEY OF MULTIMEDIA STREAMING IN WIRELESS SENSOR NETWORKS: PROGRESS, ISSUES AND DESIGN CHALLENGES
1Taner Cevik, 2Alex Gunagwera, 3Nazife Cevik
1,2Department of Computer Engineering, Fatih University
3Department of Computer Engineering, Arel University
Advancements in Complementary Metal Oxide Semiconductor (CMOS) technology have enabled Wireless Sensor Networks (WSN) to gather, process and transport multimedia (MM) data as well and not just limited to handling ordinary scalar data anymore. This new generation of WSN type is called Wireless Multimedia Sensor Networks (WMSNs). Better and yet relatively cheaper sensors – sensors that are able to sense both scalar data and multimedia data with more advanced functionalities such as being able to handle rather intense computations easily – have sprung up. In this paper, the applications, architectures, challenges and issues faced in the design of WMSNs are explored. Security and privacy issues, over all requirements, proposed and implemented solutions so far, some of the successful achievements and other related works in the field are also highlighted. Open research areas are pointed out and a few solution suggestions to the still persistent problems are made, which, to the best of my knowledge, so far haven’t been explored yet.
Multimedia, Multimedia Streaming, Wireless Sensor Networks, Wireless Multimedia Sensor Networks
Multimedia (MM), generally, is content that uses a combination of different forms of data such as text, audio, still images, video and/or animations. Enabling WSNs  to support MM data has recently become an active focus area for researchers all over the world. This is because of the availability of cheaper CMOS cameras and microphones: hardware which is rather sufficient to make this possible. Successfully achieving this goal, however, is no easy task: with it comes challenges and tough decisions to be made since there are a lot of trade-offs to consider. Like WSNs, WMSNs have a great deal of requirements – some similar to those in WSNs others more complex. In the long run, ideal WMSNs are supposed to be able to sense, retrieve, store, process, transmit and communicate, if need be, scalar data (ie. temperature, humidity, etc.) as normal WSNs - plus still images, audio and video data (MM data). This new sparking opportunity has also posed new challenges to be strived for (i.e. to meet Quality of Service (QoS), bandwidth, time restrictions among other demands required for MM data).
Owing to remarkable advancement in other related research fields such as embedded systems, computer networks, to mention but a few, advanced hardware ranging from cameras, sensor nodes, boards and the like have been manufactured. These have enabled the tackling of even more complicated problems and projects today. These problems and projects come from all sorts of application areas such as the military, health institutions, universities and other academic facilities etc.
In this paper, the prominent applications, general architecture, challenges and issues faced in the design of WMSNs are explored. The rest of this literature is organized as follows. Section II presents an overview of the original communication (protocol) stack – design goals back in the day, brief issues and challenges faced due to requirements for WMSNs today. Section III covers the challenges and issues associated with WMSNs generally. Section IV provides suggested solutions to some of the major issues ranging from security and privacy, routing to QoS problems and issues. Section V presents the available commercial and experimental MM sensors developed. Section VI covers recent, general efficiency and optimization studies. Following, section VII gives classic and new application areas of WMSNs that resulted from technological advances and progress. Lastly, section VIII concludes the paper.
2.OVERVIEW OF THE PROTOCOL STACK (TRADITIONAL DESIGN GOALS AND EXPECTATIONS)
A brief overview of the requirements and problems faced or likely to be faced at each layer of the stack is clarified in this section. For explanatory purposes, video data will be considered in the subsequent sections till further notice since audio, text and other scalar data are less demanding than video. Thus, if a solution works for videos, then it is most likely to work for audio and other scalar data as well.
2.1. MEDIA ACCESS CONTROL (MAC) LAYER REQUIREMENTS
Ordinary MAC Layer protocols designed for conventional wireless networks mainly serve the purposes such as bandwidth allocation, power optimization and awareness, collision prevention, and interference minimization . However, MM streaming requires further struggle and care in order to handle the circumstances specific to MM data transmission, such as optimizing packet latency to meet the end to end delay restrictions and also to provide priority to packets with varying service requirements whilst conserving redundant energy consumption which is the major concern cautiously cared about by the researchers during the design stage of a method or protocol for WSNs.
Suggested MAC schemes specific for WMSNs can be categorized into the following:
2.2. THE NETWORK LAYER
The protocols or methods designed for the network layer is very crucial especially for the provision of QoS in WMSNs because of the reasons as stated below:
1)Timeliness: Timeliness concept is concerned for live streaming and applications such as video conferencing, which tend to tolerate a few errors and losses. These time considering methods are broadly grouped into three categories:
2)Reliability: Applications in this category – such as Video on Demand – are less error tolerant. The commonest method for achieving reliability is the multi-path routing of which the example methods presented in [17-18]. More detailed studies in the area will be provided later in this text. The major drawbacks of ReInForm  and MMSPEED  respectively are;  requires substantial state information to be stored at intermediate sensor nodes and  does not consider delay deadlines of the packets while choosing the multiple paths.
2.3. TRANSPORT LAYER
Transport layer methods developed for traditional wired and wireless networks are mainly intended for ensuring reliable end to end data (packet) transfer, as well as, to a certain degree, congestion control. However, these issues are not vital for WSNs . This is because sensor nodes are densely deployed, so sensors might be idle with no data transfer most of the time and only become active when an event occurs. Thus, ensuring end-to-end event transfer in most WMSNs makes much more sense and would be more practically efficient than end-to-end packet transfer.
The transport protocols commonly utilized in today’s internet (such as TCP, STCP  and RTP/RTCP ) are not conceivable for WSNs regarding to the following reasons:
Notable approaches and suggestions for the transport layer can be grouped into 3:
2.4. CROSS LAYER OPTIMIZATION
Cross layer optimization covers the idea of interaction between the layers of the protocol stack in order to provide outstanding overall performance. The idea was first suggested by Schaar and Shankar in . Since providing QoS for all data sensed including MM is a challenging task, it is crucial that all layers act together. The architecture they suggest takes multimedia data (content with its features, the desired quality of services, etc.), various parameters from the other layers, the degree of adaptability, system constraints and node constraints (such as power, supported bandwidth, delay) as inputs into a system that optimizes the utility given all those constraints and gives the cross layer adaptation strategy and utility (ie. video quality, power, system-wide network utilization) as the output.
The overall approaches at this layer include:
These approaches’ major limitations are that they are either centralized or partially distributed. What is really needed are scalable distributed schemes that require less energy and message exchange. Obviously, an ideal cross layer optimization scheme should be energy aware and have a major purpose of improving QoS.
2.5. APPLICATION LAYER
One significant factor that caused the application layer to be one of the most demanding sections of the protocol stack is the process of encoding video, image and/or audio data. This is sometimes computation-intensive depending on the encoding and compression method employed.
Below are some of the main requirements that should be met at the application layer.
Recent off the shelf sensor devices are equipped with more energy supplies with embedded microprocessors, enhanced RAM and memory (generally flash), more powerful CPUs and (some very high definition) video capturing cameras as will be discussed in details subsequently.
With all these processing capabilities, video sensors still find it quite challenging to implement motion estimation and compensation techniques based on predictive coding techniques such as those used in the (Moving Picture Experts Group) MPEGx or H.26x series . This necessitates video sensors to employ compression techniques that are founded on coding mechanisms for individual still images, say, the Joint Picture Experts Group (JPEG) or JPEG 2000. Some techniques, such as those in  and , just avoid motion compensation and/or estimation altogether and instead, encode videos as sequences of images. These are the so called single layer techniques.
Efforts have been made to reduce energy consumption and simplify calculations of the compression techniques of H.26x and MPEGx based on compensation and motion estimation to make them more suitable for WSNs [37-38].
In principle, any combination of two coding paradigms and three compression techniques is possible. However, recently, distributed source coding was investigated in the context of single-layer coding and individual source coding has been explored in the context of three compression techniques used as encoding/compression schemes at the application layer.
To ensure that source coding supports transmission with minimum channel error, joint energy optimization of source code and channel coding research has been carried out as well.
Mainly two coding patterns have been investigated so far for WMSNs. These are the individual source coding and distributed source coding.
Another way of categorizing the coding techniques is the layered coding as follows: Single Layered Coding, Multi-layered coding and Multiple Description Coding (MDC) that will be briefly examined in this section. Especially a brief overview of some of the most common techniques will be identified later.
Besides reducing the amount of data, another important point is the error concealment during data transmission that is the concept of well resilience source coding. Error concealment can be solved by using Forward Error Correction (FEC) mechanisms or Erasure Correction (EC) codes . However, it is important to note that MM is too large so JPEG may result in faster energy depletion as compared to mechanisms that support aggregation. Also it should be noted that the reference frame is very important because an error in the reference frame will definitely lead to error accumulation throughout all the frames that are encoded with reference to it.
Moreover, with the existing multilayer approaches it is difficult to aggregate video data in the vicinity of the event and along the path to the base station. This is because the variable coding and redundancy levels necessitate an adaptive aggregation mechanism, thus requiring both more memory and computing power.
The above two mechanisms have got a serious demerit, it is that if the lower layer is lost at any point, either while on the path due to interference or congestion or noise, the higher layers are rendered completely useless which creates necessity for priorities among layers.
1. Both R1+R2 arrive: This is handled by a decoder – normally called the central decoder. It gives the highest image/video quality.
2. If only R1 or R1 arrive, each is received by a different decoder. Both decoders are referred to as side decoders. The both give acceptable quality but, of course, not as efficient as that given by the central decoder.
According to  and , path diversity along with MDC increases robustness in end to end communication and ensures high bandwidth in radio networks.
Apart from the above mentioned methods, many algorithms specifically for image compression have also been both suggested and developed. Most popular ones will generally be categorized and briefly mentioned in the following. According to , they can be generally categorized into two; the lossy techniques and the lossless techniques.
The lossless image techniques largely depend on two procedures:
1. Decorrelation: The stage that removes spatial redundancy between pixels. Then the image compression techniques are applied. The techniques applied after this stage fall under three categories:
2. Entropy encoding: This second stage is based on the Statistical and Run Length Coding (RLC). The covered lossy JPEG technique for images falls under this stage.
The lossy techniques result in an approximation of the original image. However, these techniques provide a higher compression ratio when compared to the lossless techniques.
3.DESIGN CHALLENGES AND PROBLEMS ASSOCIATED WITH WMSNS
Just like WSNs, WMSNs have got requirements that must be met to provide acceptable quality and fulfill inevitable constraints – especially time constraints as will be discussed later. Furthermore, constructing an efficient WMSN requires additional research support from other fields such as signal processing (especially digital signal processing), embedded systems, to mention but a few. This is because MM handling demands much more than what traditional WSNs usually do, thus a more powerful system has to be built. Some of the numerous challenges and issues faced are discussed in this section:
3.1. TIME RESTRICTIONS
These actually depend on the type of the application in question, especially important if the application requires live streaming. In this case, end to end delay should be kept as low as possible. Furthermore, in cases where live-streaming is required, more sophisticated algorithms are needed. In applications where live-streaming is not the requirement, sometimes simple methods applying basic techniques such as buffering might suffice, but then again, this might not be feasible for all MM applications as WMSNs have got limited memory with huge amounts of data to process. Thus, buffering might not always work as well.
3.2. SECURITY AND PRIVACY
This is a very important and sensitive topic as far as WMSNs are concerned. Some MM applications might demand either security, privacy or even both. Consider a bank-office monitoring application, here things like safe codes should be kept secret, in a parking yards, car number-plates should be kept secret as well. From the security point of view, some ill-intentioned people may just feed useless data to the sensors thus leading to congestion or choking the whole system, which, when worse comes to worst, might even lead to the breakdown of the whole system. Whatever the situation, security, privacy or both might be needed to be ensured – in most cases they are needed.
3.3. HUMAN HEALTH AND SAFETY ISSUES
MM sensors should not put humans in peril. This could be directly or indirectly. For example, in industries, radiations from sensors or any incidences of sensor failures and explosions should not ignite gases. Precautions should be made in advance.
Another intriguing issue is whether or not sensors radiations from radio waves actually do cause cancer to humans. The studies in people, especially those who work around radar equipment and those who service communication antennae show no clear increase in cancer risk. Given the exponential increase in number of cell phone usage and users nowadays, studies looking into possible linkages between cell phone usage and cancer were also carried out. Despite one study showing a possible link, most studies did not .
3.4. QOS REQUIREMENTS
This qualifies to be categorized as one of the most important issues to be dealt with in any WMSN. Vast amounts of research are still being carried out about this topic. Plus, as mentioned before, some applications require real-time streaming/transmission that is live-streaming.
Real time demanding applications can, however, tolerate a few losses. Thus, normally all these requirements are application specific. Hence, a given standard of service must be ensured depending on any given application.
Ways to achieve QoS are mainly through ensuring reliability, timeliness and high quality. Following from the previous section, MMSPEED is very close but it has got its own drawbacks that bar it from being ideal such as the fact that a lot of information needs to be stored in intermediate nodes. Furthermore, it cannot handle network layer aggregation.
3.5. LIMITED RESOURCES
As mentioned previously, WSNs are comprised of tiny devices with limited resources. Moreover, MM applications impose additional load on WMSNs in terms of following concepts:
3.6. ENERGY CONSUMPTION
For WSNs, energy is a vital resource, which is even of a much more paramount importance for WMSNs if a given standard of QoS is to be ensured. In WMSNs, since very huge computations are carried out, a lot of data processing and transmission of huge data are inevitable. All these operations require energy/power. Unfortunately, one of the most energy consuming operations is radio transmission, which right now is the most common means of transmission in most sensors. Apparently, there is need for energy aware algorithms for WMSNs since the fact that communication functionalities predict power consumption in WSNs does not apply to WMSNs .
We have to keep in mind that in wireless networks, bandwidth is not only limited, but also unstable. MM streaming requires very high bandwidth demands to deal with the large amounts of data ranging from scalar to multimedia. High bandwidth with low power spectral density can be provided by Ultra Wide Band (UWB) technology recently.
3.8. MM IN-NETWORK PROCESSING
Given the huge size of MM data, schemes such as aggregation would make a very great difference and solve a couple of issues concerned with WMSNs. However, even if aggregation has been successfully applied to scalar data in WSNs, it is very difficult to apply aggregation techniques to WMSNs. This is, thus, one of the open research areas for the future.
3.9. CROSS-LAYER OPTIMIZATION
Most of the problems and challenges associated with MM streaming in WSNs differ from stack layer to stack layer. The few tests and even fewer implementations in the field of WMSNs currently are mainly applied at individual stack layers. Difficult as it may be, an efficient – especially energy wise – cross-layer design would be ultimate the best.
3.10. RESOURCE ALLOCATION
Given the limited nature of the WMSN resources methods of allocating these resources throughout a network’s life time should be put so as to prolong the network’s lifespan and to make sure that the network is flexible since networks nowadays actually need to be flexible. Hybrid Automated Repeat Request (HARQ), Schedulers and other functional blocks that operate seamlessly are coupled with Dynamic Resource Allocation (DRA) techniques so as to go about this issue more so for systems that requires flexibility to transmit broad band traffic.
3.11. END-TO-END THROUGHPUT
This is responsible for the links in a WMSN – from source to sink regardless of the route used. Currently, there is no protocol specifically designed to serve this purpose yet it is of paramount importance if good performance and QoS is to be achieved. Two protocols were suggested:
Routing is another crucial challenging issue to be concerned in the field. Along with it come issues like end to end delay that results from having to transfer huge data and also rather long logged session periods. These need efficient routing algorithms. Routing becomes a complicated issue because;
A lot of research to tackle this topic has been made, but it is still an open area of research. Some of the suggested solutions will be covered later. These include; the adaptive inter spurt approach, letting the source do the transmission path selection among others, etc.
Synchronization can refer to:
3.14. FIELD OF VIEW (FOV)
FOV of a sensor is the angle through which the sensor is sensitive to events. This problem generally arises from the design of the used sensors and in most cases affects the entire WMSN as a whole. Some WMSN applications require that the network to cover a given area completely, say an auto park, a shopping mall, military camp and so forth. However, sometimes it is only required the sensors should be able to focus on a given area when an event occurs. Despite the fact that MM sensors on the market today have got relatively (to classic scalar data sensors) larger FOV and are very sensitive to the direction of data acquisition without even requiring direct LOS between the sensor itself and target object, very few of them are capable of covering the entire area, in fact none. Thus, planning for the entire network and not for individual sensors is much more feasible. Many algorithms have been proposed so far but it is still an open area of research.
This is concerned with the overall monitoring of a given field. Say an entire battlefield, industrial diagnostics and so on and so forth. Coverage designs of the current data sensors cannot be enough for MM sensors hence there is need for a new model that can support a wider coverage of the MM sensors.
Generally, reliable transport is an important issue for WMSNs, however, varies from application to application since some real time streaming applications can tolerate a few loses and some Video on Demand (VoD) applications may not be loss tolerant at all. Currently, there is no specific protocol designed to handle reliable transport issues in WMSNs. SCTP and ESRT mentioned above are quite appealing but they, too, have got their own drawbacks such as not supporting multipath, leading to delay, little or no jitter handling to mention but a few.
4.SUGGESTED SOLUTIONS TO THE MAJOR ISSUES
In this section, we will summarize the most promising solutions to the security (for data) challenges, followed by current studies, improvements and solutions to routing and QoS respectively.
The first approach suggested is to permute the position of the data bits. Of course here a known scheme of how to retrieve the data has to be used, [52-53]. However, this method does not guarantee security, yet another approach was suggested which is called Value transformation with an idea to transform or reverse the data itself, [54-55]. One that guarantees highest security so far is one that combines the above two suggestions .
As mentioned in the previous section, as far as routing is concerned; the shortest path should always be aimed for and used, wherever possible. Also the algorithms used should be as simple as possible. To increase reliability, multi path for MM data should be used.
In order to improve QoS, congestion control is vital. In , a study on the various congestion control mechanisms in WSNs, most of which are also applicable to WMSNs as well, is carried out.  Proposes a congestion control communication protocol for MM in WSNs. Authors carried out a study on using priorities together with multipath selection for videos in WMSNs . In our previous work , we propose a promising multi-channel cross-layer architecture for MM sensor networks with predetermined QoS constraints
5.THE AVAILABLE MM SENSORS, TESTBEDS AND SIMULATORS / EMULATOR (SOFTWARE AND HARDWARE)
In this section, sample MM sensors, testbeds, simulators and emulators are introduced. Compared to WSNs, MM sensors are still few. However, due to the outstanding progress in technology, many interesting ideas have been brought to life.
Below are some of the available commercial and experimental sensors available today.
Stargate is manufactured by Crossbow which has an Intel PXA 255 processor that performs at 400Hz. It is also equipped with 32MB of flash memory and 64MB of RAM. It supports computation intensive operations and has got linux OS embedded into it. It also has a 51-pin expansion connector for the MICAz/MICA2 motes and other peripherals such as resolution cameras. It has got a low power consumption. More details can be got from their online datasheet .
Even though it is no longer actively maintained or being built, this one was a mobile robot that could be extended with python, C, C++ or even Java. It’s equipped with a camera capable of communicating with IEEE 802.4 as well as ZigBee interfaces [62-63].
This is a low cost, small size and low power device that supports on-board image processing. Furthermore, it has an image processor and a CPLD as well. It is equipped with an image sensor, micro controller unit and a so called CPLD (complex programmable logic device). According to , it can be interfaced with Micaz for communication with other sensor nodes.
This camera mote has got parallel processor and various camera modules. It is a mote based on Single Instruction Multiple Data (SIMD) and designed for WMSN video analysis processor and a micro-controller (8051 micro controller). WiCa uses the IEEE ZigBee standard for its wireless communication .
This is a two-tier testbed platform composed of Sensing Agents (SAs) and Organizing Agents (OAs). IrisNet uses aggressive filtering, smart query routing and semantic caching to amazingly reduce bandwidth utilization in the network and also improve query response time.
Here webcams were used to monitor packing yards for toys. More such demonstrations and details on the platform can be found in . Two main demonstrations about parking space finder and distributed systems monitoring were carried out.
SensEye is a multi-tier (generally 3-tier) MM sensor network which is also a testbed exceptionally good for surveillance. It is, however, energy intensive and sometimes lacks reliability.
Figure 3 represents a 3-tier architecture, however 2-tier and 1-tier implementations do exist.
This sensor has got a low power CPU. It is a low cost, modular sensor built by Intel. It was designed for rather complex advanced applications and supports audio and video-imaging acceleration .
This is also a low power, low cost sensor. It is equipped with a solar battery and a solar cell. The battery is for emergencies or when the power provided by the cell is not sufficient.
This was designed for surveillance applications with high energy efficiency as a target. It provides support for in-node processing and multiple resolutions [69-70].
It is a camera network system  developed that supports in-node processing thereby reducing communication overheads. It has frequency-scalable (up to 624 MHz), 16 MB of flash and 64MB RAM.
Panoptes  is a low power good quality video sensor platform. It supports video filtering, streaming, compression and capturing.
Provides the resolution details, compression, filtering, video capturing performances and many more. However, it consumes about 5watts and has got a video resolution of 320×240. However, the authors claim that the entire device, transmitting over 802.11 consumes about 5.5 watts of power including compression while maintaining the same video resolution and capturing at 18-20 fps.
5.12. FOX BOARD BOXED SENSOR
This  was developed by acme systems with providing high quality image transmission as the main purpose. Bluetooth is used for transmitting the images captured.
6.MORE ON EFFICIENCY AND OPTIMIZATION IN WMSNS
A lot of literature has been written on the subject. In this text, we represent but a few of the proposed methods. However, most of the recent proposed methods are along the lines of multi-path streaming of MM and its variations, error concealment/correction. Below is the overview:
In , authors suggest error concealment techniques for video transmission over error-prone channels using the new H.26/AV (this is not yet supported by WMSNs –hopefully, sometime later it will) and EC, MDC and Multi-view Video Coding (MVC) techniques.
Using virtual channels leads to a more error-resilient video streaming application . According to this, virtual channels are set up and various packets are sent along those channels. Variations such as assigning priorities to promising channels can also be implemented apparently.
Another interesting idea was to use multi stream coding together with multi path video transporting . This was, however, suggested for ad hoc networks. Whether or not the methods implemented here can be used for WMSNs in general, is still an area open for research.
WMSNs have not only enhanced applications that use WSNs, but have also led to the realization of some completely new interesting applications resulting from the overtime technological advances. In this section, we cover some of them including some, but not all, applications from [77-78]:
In this study, the general architecture of WMSNs was presented along with challenges and issues associated with achieving efficient, error-resilient and energy aware WMSNs. MM sensors that have come along and those present today with their respective features were also reviewed, previous studies in the field were complemented, open research areas were pointed out, with the present applications of WMSNs already in operation. Prominent solutions to some of the challenges and issues (including the old still persistent one) that have been associated with WMSNs, progress in the field and some of the most promising studies in the area were also presented.
